COOLER MASTER MASTERBOX E500 + ELITE 500W 230V PSU, ATX, LARGE FILTERED INTAKES, SUPPORT O

Description

COOLER MASTER MASTERBOX E500 + ELITE 500W 230V PSU, ATX, LARGE FILTERED INTAKES, SUPPORT O

Large Filtered Intakes

With 500W PSU

Versatile Cooling Options

Full Black Coating & PSU Cover

Breathable Power Supply Shroud

Room For Upgrades

Removable HDD Cage

ELITE 500 ODD
STEADFAST
Large Filtered IntakesWith ODD SupportVersatile Cooling OptionsFull Black Coating & PSU CoverBreathable Power Supply ShroudRoom For UpgradesRemovable HDD CageIncluded 500W PSU

STEADFAST
The Elite 500 is the essential solution for optimised cooling. Substantial ventilation on the front panel allows fresh air into the system for both air-cooled and liquid cooled configurations.For simple tasks, the Elite 500 is a cost-effective solution to professional computing. For higher-demand tasks, the Elite 500 boasts a high compatibility for upgrades, able to house liquid cooling and provides clearance for the longest, widest graphics cards.

LARGE FILTERED INTAKES
The front panel is constructed with a substantially large, unrestricted intake grill to provide superb airflow to the system.

VERSATILE COOLING OPTIONS
Support for up to six fans and front, top, and rear radiator support ensure that performance is not compromised.

WITH ODD SUPPORT
The ODD version of the Elite 500 is slightly deeper in comparison to its non-ODD counterpart.

FULL BLACK COATING & PSU COVER
Let your system stand out with an all-black background and a PSU cover to hide cables.

BREATHABLE POWER SUPPLY SHROUD
The PSU cover is ventilated on top of the power supply location, this allows actively cooled units to be installed either with the fan facing the top or bottom, also with the possibility of installing passively cooled power supplies. The Elite 500 comes preinstalled with a 500W power supply.

STEEL LEFT SIDE PANEL
The ELITE 500 ODD Features a steel side panel for those who prefer a stealthy minimalist look.

ROOM FOR UPGRADES
Support for up to a 400mm graphics card in the ODD version, a 161mm CPU cooler, and multiple fans/radiators locations provides room for upgrades to stay ahead of the game.

HEADSET JACK
The single 4 pole headset jack features both Audio and Microphone capabilities simultaneously so that separate jacks are not needed.

VERSATILE HDD CAGE
The HDD cage is (re)movable. The cage can be shifted forward to make room for a longer PSU, backwards for additional radiator space, or completely removed if HDD storage is not needed.

AMPLE STORAGE SUPPORT
Elite 500 comes with support for up to 2x 3.5″ and up to 5x 2.5″ drives.Storage can be mounted behind the motherboard tray and withing the versatile HDD cage

100% TOOL-LESS MOUNTING
The case implements Cooler Master’s exclusive tool-less storage mounting system. Easy, fast and secure mounting guaranteed without the need for any screws.

SPECIFICATIONS

SERIES
Elite Series

SIZE
Mid Tower

MODEL NUMBER
E500-KN5N50-S00 (Steel, ODD + 500W Power Supply)

COLOUR(S)
Black

MATERIALS
Steel, Plastic

DIMENSIONS (L X W X H)
464 x 204 x 455mm (incl Protrusions, ODD)457 x 204 x 455mm (excl. Protrusions, ODD)

VOLUME
42.40L (exlc. Protrusions)

MOTHERBOARD SUPPORT
Mini ITX, Micro ATX, ATX

EXPANSION SLOTS
7

KENSINGTON LOCK
N/A

5.25″ DRIVE BAYS
1

2.5″ / 3.5″ DRIVE BAYS (COMBO)
2

2.5″ DRIVE BAYS
5

I/O PANEL
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)

PRE-INSTALLED FANS – REAR
1x 120mm

FAN SUPPORT – TOP
2x 120mm, 2x 140mm

FAN SUPPORT – FRONT
2x 120mm, 3x 120mm (remove ODD bracket)

FAN SUPPORT – REAR
1x 120mm

RADIATOR SUPPORT – TOP
120 / 240mm (32mm max motherboard component height)

RADIATOR SUPPORT – FRONT
120mm, 140mm, 240mm, 280mm, 360mm (Remove ODD)

RADIATOR SUPPORT – REAR
120mm

CLEARANCE – CPU COOLER
Steel: 163mm

CLEARANCE – PSU
180mm

CLEARANCE – GFX
400mm (w/o front fans & radiator)

CABLE ROUTING
18.5mm

DUST FILTERS
Front, Top, Bottom

POWER SUPPLY
Bottom Mount, ATX – 500W Included

WARRANTY
2 Years
