FSP HTI-1000M-GEN5 Hydro Ti PRO 1000W 80 Plus Titanium Fully Modular ATX 3.0 Power Supply

Description

Hydro Ti PRO 1000W

New ATX PSU Specifications
Updated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency. Click here to know more details.

Ultra Power Density
Compared to general high-efficiency & high wattage PSU 170mm length, Hydro Ti PRO series delivers high power with shorter size of 150mm.

80 Plus® Titanium Certification
Hydro Ti PRO series is a power supply with 80 PLUS® Titanium provides over 94% efficiency at the load of 50 % and Cybenetics-certified for lower power consumption.

Smarter, Quieter and Longer Lasting Eco Friendly Fan
Under 50% loading, you will enjoy Zero RPM experience when eco semi-fanless fan control switch is on, , and get the benefit of long lifespan from a 135mm fluid dynamic bearing fan.

Lambda A++ Certification
Hydro Ti PRO ATX3.0(PCIe5.0) 1000W got Lambda A++ noise rating. By averaging the noise measurements that take from Cybenetics test results.

PSU Noise Level Certifications

NOISE LEVELS (115V/230V INPUT)
NOISE REQUIREMENTS

A++
<15 dB(A)

A+
≥15 dB(A) & <20 dB(A)

A
≥20 dB(A) & <25 dB(A)

A-
≥25 dB(A) & <30 dB(A)

STANDARD ++
≥30 dB(A) & <35 dB(A)

STANDARD +
≥35 dB(A) & <40 dB(A)

STANDARD
≥40 dB(A) & <45 dB(A)

*Source from Cybenetics website.

Off-Wet, Off-Dust and Off-Stain Coating
Covered with exclusive conformal coating which guarantees to offer better and reliable performance in harsh environments and is tested to work in environments up to 95% relative humidity.

LLC Topology
Zero voltage switching of the main switches thereby dramatically lowering switching losses and boosting efficiency.
450V, 105°C Japanese E-Capacitors
Hydro Ti PRO series uses Japanese bulk capacitors to ensure a longer lifetime and protect your equipment from the infamous capacitor leakage problem.

Unleash +12V Power Output
VGA card is a power-hungry component that needs most power. A single +12V rail design can deliver stable power and avoid any overloading conditions.

Fully Modular Design
Fully-modular design not just for easier installation, but also provides your system a neat and tidy look.

Stylish & Changeable Side Sticker
Includes unique side stickers for DIY enthusiasts and gamers.

Cable Length
A unit of length: mm

Motherboard

CPU

PCIe 6+2 Pin

PCIe 6+2 Pin

PCIe 12VHPWR

SATA

SATA

SATA / MOLEX

Cables



ATX 24
4+4 PIN
12VHPWR
PCIe 6+2
SATA
Molex

Connectors
1
2
1
5
12
4

AC/DC

AC Input
100-240Vac~  13-6A  50-60Hz (Not for China, Korea)

200-240Vac~  6A        50-60Hz (Only for China, Korea)

DC Output
+3.3V
+5V
+12V
-12V
+5Vsb

Max Output Current
20A
20A
83.33A
0.3A
3A

Max Combined Power
120W
1000W
18.6W

Total Power
1000W

SPECIFICATIONS

Model
HTI-1000M,Gen5

Rated Output Power
1000W

Form Factor
ATX

80 PLUS Certification
Titanium

Input Voltage
100-240V ; 200-240V

Input Current
13-6A ; 6A

Input Frequency
50-60Hz

PFC
Active PFC

Efficiency
94%

Fan Type
FDB fan, 135mm

Dimensions(L x W x H)
150×150×86 mm

Protection
OCP, OVP, OPP, SCP, OTP
